Ex Display Mic, comes with DPA full  warranty

Big sound - small footprint

  • Exceptional audio quality

  • Uniform, consistent sound between DPA mics

  • Extremely rugged and reliable

  • Diminutive size made for flexible and easy concealment

  • Large selection of clips, windscreens, grids and other accessories

  • Modular adapter system fits most professional wireless systems



Specifications


Directional characteristics: Omnidirectional
Principle of operation: Pressure
Cartridge type: Pre-polarized condenser element with vertical diaphragm
Frequency range, ± 2 dB: Soft boost grid: 20 Hz – 20 kHz, 3 dB soft boost at 8 – 20 kHz. High boost grid: 20 Hz – 20 kHz, 10 dB boost at 12 kHz.
Sensitivity, nominal, ±3 dB at 1 kHz: 6 mV/Pa; -44 dB re. 1 V/Pa
Equivalent noise level A-weighted: Typ. 26 dB(A) re. 20 µPa (max. 28 dB(A))
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL): 68 dB(A)
Dynamic range: Typ. 97 dB
Max. SPL, peak before clipping: 144 dB
Output impedance: 30 – 40 ohm
Cable drive capability: Up to 300 m (984 ft)
Power supply: For wireless For wireless systems: Min. 5 V – max. 50 V through DPA adapter. With DAD6001-BC/DAD6024/DAD4099: 48 V phantom power ±4 V for full performance.
Connector: MicroDot
Color: Black, beige, brown or white
Microphone weight: 7.5 g (0.26 oz) incl. cable and MicroDot connector
Microphone diameter: 5.4 mm (0.21 in)
Microphone length: 12.7 mm (0.5 in)
Cable length: 1.8 m (5.9 ft)
Polarity: Positively increasing sound pressure produces positive going voltage on MicroDot pin
Temperature range: -40 °C to 45 °C (-40 °F to 113 °F)
Relative Humidity (RH): Up t 90%
SKU DP-SC4061-FM
Brand DPA
Unit Of Measure ea
