Eminence CANNABIS REX™ 16 12″ Lead / Rhythm Guitar Speaker- American 50w – 16 ohm

Name: Eminence CANNABIS REX™ 16 12" Lead / Rhythm Guitar Speaker- American 50w - 16 ohm
Brand: EMINENCE
SKU: CANNABISREX-16
Availability: InStock

Eminence CANNABIS REX™ 16 12" Lead / Rhythm Guitar Speaker- American 50w - 16 ohm - Image 2

Eminence CANNABIS REX™ 16 12" Lead / Rhythm Guitar Speaker- American 50w - 16 ohm - Image 3

Original price was: $349.00.Current price is: $299.00.



FAST
Delivery



EASY
Returns



IN HOUSE
Repairs

2 in stock

Pick-up from store - FREE
Free pickup from our Melbourne Store at 4 Drake Boulevard, Altona VIC 3018. Your order will typically be ready by the next business day. We recommend calling us on (03) 8360 7799 beforehand to check it's ready for collection.

Description
Additional information

The Eminence Cannabis Rex™ guitar speaker lets your laid-back style come through. Clean and full, with lots of body and sparkle. Smokey smooth with high-end definition. Country, Jazz or Classical guitarists take notice.

SeriesPatriotsModelCannabis Rex™Application12" Open or Closed BackConfiguration1, 2, or 4 X 12"Low End ResponseAggressiveLow End ShapeFat/RoundMid-Range ResponseModerateMid-Range ShapeWarmHigh-End ResponseModerateVolume/PowerLoudestOverall Coloration*Clean and full, with lots of body and sparkle. Smokey smooth with high-end definition.Break-up ModesSlowPower RangeUp to 50 wattsInstrument*Lead/Rhythm Guitar, Acoustic Guitar, KeyboardGenre of Music*Country, Jazz, Classical

SPECIFICATION
Nominal Basket Diameter	12", 305 mm
Nominal Impedance*	16 Ω
Power Rating*
Program Power	N/A
Watts	50 W
Resonance	101 Hz
Usable Frequency Range	80 Hz - 4.2 kHz
Sensitivity*	101.8 dB
Magnet Weight	38 oz.
Gap Height	0.312", 7.9 mm
Voice Coil Diameter	1.75", 44 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)	101 Hz
DC Resistance (Re)	13.1 Ω
Coil Inductance (Le)	0.75m H
Mechanical Q (Qms)	9.95
Electromagnetic Q (Qes)	0.82
Total Q (Qts)	0.75
Compliance Equivalent Volume (Vas)	36.4 liters / 1.29 cu.ft.
Peak Diaphragm Displacement Volume (Vd)	42.6 cc
Mechanical Compliance of Suspension (Cms)	0.09 mm/N
BL Product (BL)	16.7 T-M
Diaphragm Mass Inc. Airload (MMs)	27 grams
Efficiency Bandwidth Product (EBP)	124
Maximum Linear Excursion (Xmax)	0.8 mm
Surface Area of Cone (Sd)	532.4 cm2
Maximum Mechanical Limit (Xlim)	N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed	Acceptable
Vented	Acceptable
Driver Volume Displaced	0.071 cu.ft. / 2 liters
Overall Diameter	12.03", 305.6 mm
Baffle Hole Diameter	11.07", 281.2 mm
Front Sealing Gasket	Yes
Rear Sealing Gasket	Yes
Mounting Holes Diameter	0.25", 6.4mm
Mounting Holes B.C.D.	11.59", 294.4mm
Depth	5.1", 129.5 mm
Net Weight	8.2 lbs, 3.72 kg
Shipping Weight	9.8 lbs, 4.45 kgs
MATERIALS OF CONSTRUCTION
Coil Construction	Copper voice coil
Coil Former	Paper former
Magnet Composition	Ferrite magnet
Core Details	Non-vented core

Basket Materials	Pressed steel basket
Cone Composition	Hemp paper cone
Cone Edge Composition	Paper cone edge
Dust Cap Composition	Zurette dust cap
