Enables you to record up to 22 individual channels directly to an SD card, supplies you with custom headphone mixes for up to six band members, and delivers a polished live mix — complete with studio-quality effects.



Features:



• 20-channel rackmount digital mixer (16 mono/2 stereo)

• 22-in/4-out USB audio interface for your Mac, PC, or iOS device (Apple Lightning-to-USB Camera Adapter is required for iOS)

• 22-track 24-bit/96kHz recording directly to an SD card

• Record up to 48kHz to a computer and an SD card simultaneously

• Create customizable, savable headphone mixes for up to 6 band members

• Complete your entire project on the mixer, or transfer all 22 discrete tracks to your DAW for editing and mixing

• 16 combo jacks accommodate both XLR and 1/4" connectors

• 16 great-sounding mic preamps with phantom power and +60dB of gain

• Channels 1–2 offer hi-Z inputs for your electric guitar or bass

• Channels 17/18 and 19/20 have TRS and RCA connectivity for keyboards and other audio devices

• Each channel features a 3-band mid-parametric EQ and 20 built-in effects

• Channels 1–16 include a dedicated compressor for controlling dynamics

• Channels 3–16 have a -26dB pad for capturing loud sources

• Clear 12-segment LED metering for keeping an eye on your levels

• Save up to 9 scenes and recall your custom settings automatically

• FOH engineer and 6 musicians can take command of their own mix via the Remote Mixer app for iPad



Tech Specifications:



• Type:Rackmount Digital Mixer

• Channels:20 (16 x mono, 2 x stereo)

• Inputs - Mic Preamps:2 x XLR-1/4" combo (mic/line/Hi-Z), 14 x XLR-1/4" combo (mic/line)

• Phantom Power:16 channels

• Inputs - Line:2 x Dual RCA Stereo (line), 4 x 1/4" (2 x stereo line)

• Outputs - Main:2 x XLR (master)

• Aux Sends:6 x 1/4" (monitor out A-F)

• Remote:1 x 1/4" (control footswitch)

• USB:1 x Type B, 1 x Type A

• Computer Connectivity:USB (22 x 4)

• Bluetooth:BTA-1 Adapter (included)

• Headphones:1 x 1/4"

• A/D Resolution:24-bit/96kHz

• EQ Bands:3-band EQ, Low Cut

• Effects:20 x Effects; Reverb, Delay, Chorus

• Signal Processing:Compression

• Transport Controls:Yes

• Storage:SDHC (max 32GB), SDXC (max 512GB)

• Software:Remote Mixer app, L-20 Control iPad app

• Rackmountable:Yes (rack ears included)

• Power Source:12V DC external power supply (included)

• Height:5.97"

• Depth:6.22"

• Width:17.24"

• Weight:5.4 lbs.

• Manufacturer Part Number:ZL20R



Note: iPad required for operation. Compatible with all iPad Air models, iPad Mini 2 and later, iPad Pro, and iPad (2017), running iOS 10.3.3 or newer. iPadOS 13 is not currently supported.
